55觸控顯示器,led觸控螢幕,商用觸控顯示器
55吋 4k 電容觸控顯示器 (TTCP4K55) |
55吋 電容觸控顯示器 (TTCP55) |
|
Aspect Ratio |
16:9 |
|
Resolution |
3840 x 2160 |
1920 x 1080 |
Max brightness |
400cd/㎡ (typical) |
350cd/㎡ (typical) |
Dot pitch |
0.315 mm x 0.315 mm x RGB |
0.1615H x 0.4845W mm |
Display color |
10bit(D), 1.06Billon colors |
10 bit(8+FRC), 1073.7M |
View angel |
176° (H), 176°
(V) |
|
Input signal |
15 Pin D-Sub , AV,色差端子,
HDMI,USB2.0/3.0 , SD卡,嵌入式電視接收端子, ARMCortexA9双核心CPU , Android4.2 |
15Pin D-Sub ,HDMI,USB,AV |
V/H frequency |
50-75Hz / 31-64KHz |
|
Reponse time |
8ms |
5ms |
Display area |
1207(L) x 682(H)mm |
|
Contrast ratio |
2500:1 (typical) |
|
Digital signal |
480p,525i,525P,720P,1080i,1080p高畫質數位 FULL
HDTV |
|
Weight |
30KG |
|
Dimensions |
L1295 x D35 + 40 x H770 mm |
|
Max power consumption |
INPUT 100~240VAC 50/60HZ 1.5A |
|
Audio output |
10W x 2 |
|
Power consumption |
4W(STANBY),90-100W(WORKING) |
|
Dynamic contrast ratio |
1,000,000:1 |
觸控功能
55吋 4k 電容觸控顯示器 (TTCP4K55) |
55吋 電容觸控顯示器 |
|
Touch accuracy |
<2.5mm |
|
Resolution rate |
25像素/分鐘 |
|
Touch method |
手指/電容摸筆 |
|
Interface |
投射式耦合電容 |
|
Surface hardness |
3H(P/G) |
|
Transparency |
90% |
|
Max resolution |
4096x4096(Automatic matching) |
|
Max support Points |
2/4/6/10 points |
|
Control type |
PCBA control board |
|
Connector type |
USB2.0 |
|
Supply voltage |
USB 5VDC |
|
Power consumption |
Active Mode:<200MA.ldie Mode:20MA |
|
Oscillator Frequency |
12MHz |
|
Response Time |
<6ms |
|
Min. report rate |
10PT:80Hz |
|
Max. operating frequency |
150MHZ |
|
Max. air discharge |
8KV |
|
ESD contact discharge |
4KV |
|
Operating system |
Windows 2000/CE/ XP/ 7/8/8.1/ 10 /
Linux/安卓/ DOS等 |
|
Adapter ripple |
Vpp<50mv |
