43吋紅外線觸控顯示器,IR觸控螢幕,商業用觸控螢幕
★ multi-touch functionality
★ dust-proof / explosion-proof / anti-static treatment
★ industrial-grade display panel, hard material
★ automatic playback system, USB plug-and-play
- can be set to any point in time to play
★ infrared body sensors play
★ smoke detector off Alarm system
Product benefits are
presented in high resolution, with perfect color and lifelike
electronic digital playback, real-time modification of the content
without printing paper, reducing paper consumption,
improving real-time interaction, and effectively gathering crowds
Product specification
|
43 -inch infrared touch screen- 4K | |
|
Aspect Ratio |
16:9 |
|
Resolution |
3840 X 2160 |
|
Max brightness |
350cd/ ㎡ (typical) |
|
Dot pitch |
0.4845H x 0.4845V mm |
|
Display Color |
10 bit(8+FRC), 1073.7M |
|
View angel |
176 ° (H), 176 ° (V) |
|
Input signal |
15Pin D-Sub , HDMI , USB , AV |
|
V/H frequency |
50-75Hz / 31-64KHz |
|
Response time |
5ms |
|
Display Area |
940.896(H) x 529.25(V)mm |
|
Contrast ratio |
2500:1 (typical) |
|
Digital signal |
480p, 525i, 525P, 720P, 1080i, 1080p, FULL HDTV signal |
|
Weight |
24.8KG |
|
Dimensions |
L998 x D59 x H586 mm |
|
Audio output |
10W x 2 |
|
Touch function | |
|
Touch points |
More |
|
Effective touch area |
933 X 526 |
|
Screen structure |
The transmitting or receiving control circuit and the controller are installed in the aluminum alloy frame, and 3~5mm tempered glass can be pasted on the back |
|
Touch resolution |
32767X32767 |
|
positioning accuracy |
<3mm |
|
Response time |
<10ms |
|
Transmittance |
≥ 90 % |
|
brightness |
≥ 350cd/m2 |
|
Durability |
Anti-scratch, can withstand more than 50.000.000 times of single touch |
|
Surface hardness |
Can withstand a 1kg steel ball falling from a height of 1 meter without breaking (the broken fragments will not cause harm to the human body ) |
|
MTBF |
≥ 5000 hours |
|
Support system |
Windows 2000/CE/ XP/ 7/8/8.1/ 10/Linux/ Android /DOS, etc. |
|
Interface method |
USB2.0 |
|
