46吋 拼接電視牆

  Aspect ratio

16:9

  Resolution

1920 x 1080

  Display area

1018.08(H) x 572.67(V)mm

  View angel

176°(H) / 176°(V)

  Brightness(typical)

500cd / ㎡

  Reponse time

5ms

  Contrast ratio

3500 : 1 (typical)

  Dot pitch(mm)

0.53025(H) x 0.53025(V)

  Display color

262K(typical) / 16.7M (supported)

  Input signal

15 Pin D-Sub , HDMI , USB

  V/H frequency

50-75Hz / 31-64KHz

  Digital signal

480p,525i,525P,720P,1080i,1080p FULL HDTV

  Weight

13.5KGS

  Audio output

10W x 2

  Dimensions(mm)

1021.98(H) x 576.57(V) x 30.00(D) + 47.00mm

  Max power consumption

INPUT 100~240VAC 50 / 60HZ 3A

  Operation temperature

-20°C-50°C / D205%-95%(humidity)

  Power consumption

 3W(standby) / 120-130W(working)
